Sandsun VS10 is a series of hydraulic overload protectors of the Large Flow Type, using a spring mechanism (Spring Type). Although typically specified for press machines from 200 to 600 tons, the VS10 is also an excellent upgrade choice for press machines under 200 tons when faster and more powerful oil discharge capability is needed to protect expensive, sensitive die sets.
Sandsun VS10 with large flow discharge capability.
With a larger orifice area compared to the standard VS08 series, the VS10 can release a large amount of oil in an extremely short time, dissipating overload pressure almost instantly. The device retains the advantages of the spring series: high stability, ease of installation, and maintenance.
✨Key Features of the VS10 Series
1. Large Flow Discharge
Special design allows for discharging a larger amount of oil in the same time period compared to standard models, enhancing protection capability.
2. Mechanical Stability
Using a spring to set the pressure helps the device operate stably, less affected by environmental factors such as air supply.
3. Automatic Operation
Automatically detects overload, stops the machine, and automatically refills hydraulic pressure to be ready for the next working cycle.
