YMNRF Series: Micro NC Roll Feeder (Thin Material 0.1-1.6mm)

Views:
113
Product Code:
YMNRF
Price:

Contact

Description:

The Youngrim YMNRF Series Micro NC Roll Feeder is a high-speed, ultra-compact solution specialized for thin materials (0.1-1.6mm). Featuring an economical design and in-house numeric control , the YMNRF is ideal for high-speed stamping of small, thin parts, achieving high SPM at short pitches. It includes a feeding roll thickness adjusting unit, ensuring precise feeding of thin plate.

Micro NC Servo Feeder – Youngrim YMNRF Series

High-speed, ultra-compact solution for thin materials.

Brand: Youngrim (Korea)

Youngrim's YMNRF (Micro NC Roll Feeder) Series is a high-speed servo feeder, specially designed for stamping small, intricate parts from thin materials. With the ability to achieve very high SPM (strokes/minute) at short feed pitches, this is an economical and effective solution.

This equipment is specialized for materials with thicknesses from 0.1mm to 1.6mm (or 2.3mm depending on the model). The unique feature of YMNRF is the feed roll thickness adjuster, which allows for clamping and feeding ultra-thin materials accurately without marking or damaging the material. The 'in-house' digital controller makes the machine compact, economical, and easy to operate.

✨Key Features of the YMNRF Series

1. Specialized for Thin Materials

Equipped with a feed roll thickness adjuster, ideal for feeding thin plates with high accuracy.

2. High Speed & Economical

Compact and economical design thanks to the 'in-house' digital controller. Optimized for high-speed stamping with short feed pitches (e.g., 300 SPM at 10mm pitch).
