Youngrim's NC Zigzag Feeder is a specialized system designed to maximize material utilization. By providing programmed left-right movement (zigzag feeding), it allows for nested blanking of round or irregular parts, significantly reducing scrap. This system is controlled by an AC Servo and Touch Panel , and is designed to integrate with the YNLF (H, M, S, E) series of leveller feeders.

NC Servo ZIGZAG Feeding System – Youngrim

The material maximization solution (scrap saving) for blanking.

Brand: Youngrim (Korea)

In stamping production, especially when blanking round or irregularly shaped parts, scrap accounts for a very large proportion, causing a waste of material costs. Youngrim's NC Zigzag Feeding System is specially designed to solve this problem, helping to maximize material utilization.

This device is an NC feeding system that, in addition to its forward feeding capability (by AC Servo Motor), also has the ability to move laterally (left-right). This travel distance is easily controlled via a Touch Panel. As a result, the die can stamp parts alternately on the material strip, minimizing scrap to the maximum extent.

This system is designed to be integrated and operate synchronously with Youngrim's main NC Leveller Feeder lines, including the YNLF H, M, S, and E Series.

✨Key Features of the ZIGZAG Series

1. Material Maximization

This is the biggest advantage, designed for maximum scrap saving, especially effective for blanking round, oval, or irregularly shaped parts.

2. Easy Operation

The feeding pitch and the left-right travel distance are both easily set and controlled via the touch screen. Operators without high skills can still use it.
